TP-Link TL-SF1008D 10/100Mbps 8 portos mini switch
HARDVER JELLEMZŐK Szabványok és protokollok IEEE 802.3, IEEE 802.3u, IEEE 802.3x CSMA/CD Csatlakozások 8 db 10/100 Mb/s Port, Auto-Negotiation, Auto-MDI/MDIX Ventilátorok száma Ventilátor nélküli Hálózati tápegység Külső tápegység (9VDC / 0,6A) Energiafelvétel Maximum: 2,05W (220V/50Hz) Külső tápellátás 100-240VAC, 50/60Hz Puffer méret 768 Kb Adatsebesség 10/100 Mb/s - Half Duplex 20/200 Mb/s - Full Duplex LED jelzőfény Táp, 1, 2, 3, 4, 5, 6, 7, 8 port Méretek (Sz x Mé x Ma) 134,5 x 79 x 22,5 mm (5.3 x 3.1 x 0.9 in.) Max. áramfelvétel 2.05W(220V/50Hz) Max Heat Dissipation 6.99BTU/h SZOFTVER JELLEMZŐK Továbbítás módja Tárolás és továbbítás További funkciók Zöld technológia 802.3X (folyamfelügyelet) Flow Control, forgalmi szűrés (Back Pressure) EGYÉB JELLEMZŐK Tanúsítványok FCC, CE, RoHS Csomagolás tartalma 8 portos 10/100 Mb/s asztali Switch TL-SF1008D Tápegység Felhasználói útmutató Környezet Működési hőmérséklet: 0?~40 ? (32 ?~104?) Tárolási hőmérséklet: -40?~70 ? (-40 ?~158?) Működési Páratartalom: 10%~90% változatlan halmazállapot Tárolási Páratartalom: 5%~90% változatlan halmazállapot
D-Link DGS-1008D 10/100/1000Mbps 8 portos switch
The DGS-1008D 8-Port Gigabit Desktop Switch is part of D-Link’s series of SOHO devices that allows you to easily expand and upgrade your network. D-Link’s Green Technology provides energy savings, reduces heat, and a longer product life without sacrificing performance or functionality. DGS-1008D provides eight Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity. An energy-efficient power adapter (Energy Star Level V qualified), minimised use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly. Fast and Reliable Networking The D-Link DGS-1008D 8-Port Gigabit Desktop Switch creates a blazing fast network for your office, as its Gigabit Ethernet ports provide high-speed wired connections for up to eight PCs or other devices. The DGS-1008D also features QoS, which prioritises network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. It’s stylish, easy-to-use, and comes IPv6-ready for a reliable network today and tomorrow. Conserve Energy The 8-Port Gigabit Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports. It also adjusts the amount of power supplied to a port according to the length of the connected Ethernet cable. Environmentally-friendly The 8-Port Gigabit Desktop Switch was designed with the environment in mind, and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimise the use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive. Specs Download the datasheet. Type Unmanaged Number of ports 5 to 14 ports Main type of ports 1000BASE-T Gigabit Ethernet Switching capacity 16 Gbps Fanless yes D-Link Green yes 802.3az Energy-Efficient Ethernet support yes Form Factor Desktop Housing Plastic Jumbo frame yes Cable diagnostics yes MAC address 4K Number of QoS queues per port 4
D-Link DGS-1016D 10/100/1000Mbps 16 portos Desktop switch
Technical Specifications: D-Link DGS-1016D/DGS-1024D Specifications General Number of Ports Sixteen 10/100/1000 Gigabit ports Twenty-four 10/100/1000 Gigabit ports Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet ANSI/IEEE 802.3 NWay auto-negotiation IEEE 802.3x Flow Control Data Tranfer Rates Ethernet: 10 Mbps (half duplex) 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex) 200 Mbps (full duplex) Gigabit Ethernet: 2000 Mbps (full duplex) Network Cables 10BASE-T: UTP CAT 3, 4, 5/5e (100 m max) EIA/TIA-586 100-ohm STP (100 m max) 100BASE-TX, 1000BASE-T: UTP CAT 5/5e (100 m max) EIA/TIA-568 100-ohm STP (100 m max) Functionality D-Link Green Features IEEE 802.3az Energy Efficient Ethernet (EEE) Link status detection power saving Cable length detection power saving RoHS Compliance Media Interface Exchange Auto MDI/MDIX Transmission Method Store-and-Forward switching method MAC Address Table 8K MAC addresses RAM Buffer 512 KBytes RAM for data buffering Jumbo Frames 9216 Bytes 9600 Bytes Switching Capacity 32 Gbps 48 Gbps Port Packet Filtering 10M: 14,880 pps 100M: 148,800 pps 1000M: 1,488,000 pps Physical LEDs Power LED 16 Link/Activity/Speed LEDs (one per port) Power LED 24 Link/Activity/Speed LEDs (one per port) Power Inputs 100 to 240V AC Input Power Consumption Standby: 4.48 watts Maximum: 9.84 watts Standby: 6.5 watts Maximum: 13.5 watts Heat Dissipation Standby: 15.2768 btU/h Maximum: 33.5544 btU/h Standby: 22.165 btU/h Maximum: 44.035 btU/h MTBF 795,539 hours 633,536 hours Dimensions 11.02 x 4.92 x 1.73 inches (280 x 125 x 44 mm) 11.02 x 7.09 x 1.73 inches (280 x 180 x 44 mm) Weight 2.34 lbs (1.06 kg) 3.66 lbs (1.66 kg) Operating Temperature 32 to 104 °F (0 to 40 °C) Storage Temperature 14 to 158 °F (-10 to 70 °C) Humidity 5% to 90% non-condensing Certifications FCC Class A ICES-003 Class A CE Class A C-Tick Class A CB cUL
GIGALIGHT BIDI SFP modul, 1.25G, 1550/1310nm, 20km távolság, 0~70 hőm. tart., DDM funkció, LC
A Gigalight optikai modulok minőségi komponensekből modern gyártási technológiával készülő nagy megbízhatóságú termékek, amelyek elsősorban telekommunikációs, adatközponti és kritikus fontosságú alkalmazások kiszolgálását célozzák. Az optikai modulok az összes jelentős hálózati eszköz gyártó berendezéseiben használhatók, a kívánt kompatibilitás a modulok megrendelésénél választható ki. Az 1000BaseBX-D SFP Bidi (Egyszálas) modul főbb tulajdonságok 1.25G adatkapcsolati sebesség 20km távolság 9/125µm monomódusú optikai kábelen Szimplex LC/UPC optikai csatlakozó SFF-8472 szabványos digatal diagnostic monitoring (DDM) Üzem közben cserélhető (hot swappable) Fémházas kivitel, alacsony elektromágneses interferencia (EMI) VCSEL lézer adó és PIN vevődióda +3.3V tápellátás Üzemi hőmérséklet tartomány (a burkolaton mérve):0°C és +70°C között Támogatott protokollok és alkalmazások Gigabit Ethernet 1G Fiber Channel Switchek közötti összeköttetések Router/szerver interfész Egyéb optikai összeköttetések Kompatibilis minden Cisco, D-Link, Mikrotik, Ubiquiti, Tp-Link, Zyxel eszközzel.
MERCUSYS Switch 5x1000Mbps (4xPOE+), Fémháza Asztali, MS105GP
Dimensions 99.8*98*25mm PoE Ports RJ45 Standard: Compliant with 802.3 af/at Powered Devices PoE Ports: Port 1- Port 4 PoE Power Budget: 65 W Interfaces 5× 10/100/1000Mbps Ports, Auto-Negotiation, Auto MDI/MDIX External Power Supply External Power Adapter (Output: 53.5V/1.31A) Installation Desktop Wall Mount Standards and Protocols IEEE 802.3x Flow Control Data Rates 10/100/1000 Mbps at Half Duplex 20/200/2000 Mbps at Full Duplex Jumbo Frame 9 KB Mac Address Table 2K Max Power Consumption 3.13W(220 V / 50 Hz, no PD connected) 75.15W(220 V / 50 Hz, with 65W PD connected) Max Heat Dissipation 10.64 BTH/h (no PD connected) 255.51 BTH/h(with 65W PD connected) Hardware Package Contents • 5-Port Gigabit Desktop Switch with 4-Port PoE+(MS105GP) • Power Adapter • Quick Installation Guide Environment Operating Temperature: 0?~40? (32?~104?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% RH non-condensing Storage Humidity: 5%~95% RH non-condensing Others
D-LINK Switch 5x1000Mbps Műanyagházas Asztali, GO-SW-5G/E
Technical Specifications: GO-SW-5G GO-SW-8G Switching Fabric 10 Gbps 16 Gbps Standards IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper) ANSI/IEEE 802.3 NWay auto-negotiation IEEE 802.3x Flow Control IEEE 802.3az Energy-Efficient Ethernet (EEE) Protocol CSMA/CD Data Transfer Rat Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex Gigabit Ethernet: 2000 Mbps (full duplex) Topology Star Network Cables 10BASE-T: UTP CAT 3, 4, 5/5e (100 m max.) EIA/TIA-586 100-ohm STP (100 m max.) 100BASE-TX: UTP CAT 5/5e (100 m max.) EIA/TIA-568 100-ohm STP (100 m max.) Media Interface Exchange Auto MDI/MDIX adjustment for all ports LED Indicators Per port: Link/Activity/Speed Per device: Power Transmission Method Store-and-forward MAC Address Table 2K 8K MAC Address Learning Automatic update Packet Filtering/Forwarding Rates Ethernet: 14,880 pps per port Fast Ethernet: 148,800 pps per port Gigabit Ethernet: 1,488,000 pps per port RAM Buffer 128KB per device Jumbo Frames 9,216 Bytes General Specifications DC Input External 5 V/1 A Level "V" Power Adapter Power Consumption DC input: 1.67 watts AC input: 2.7 watts DC input: 3.06 watts AC input: 3.9 watts MTBF 815,700 hours 412,433 hours Operating Temperature 23º to 104º F (0º to 50º C) Storage Temperature 14º to 158º F (-10º to 70º C) Operating Humidity 10% to 90% RH non-condensing Storage Humidity 5% to 90% RH non-condensing Dimensions 3.8 x 3.1 x 1.1 inches (97 x 79 x 28 mm) 5.16 x 3.23 x .9 inches (128 x 68.5 x 25.4 mm) Weight 3.688 ounces (105 grams) 4.88 ounces (138.3 grams) Certifications FCC Class B ICES-003 Class B CE Class B C-Tick Class B VCCI Class B cUL/UL CCC Anatel LVD
D-LINK Switch 5x1000Mbps + 2x2.5Gbps Multi-Gigabit Fémházas Asztali, DMS-107/E
Type Unmanaged Number of ports 5 to 14 ports Main type of ports 1000BASE-T Gigabit Ethernet Type of uplink ports 2.5GBASE-T Ethernet Switching capacity 20 Gbps Fanless 802.3az Energy-Efficient Ethernet support Form Factor Desktop Housing Metal Number of QoS queues per port 8 (Gigabit ports only)
MERCUSYS Switch 6x100Mbps(4xPOE+), Fémházas Asztali, MS106LP
Dimensions 99.8*98*25mm PoE Ports RJ45 Standard: Compliant with 802.3 af/at Powered Devices PoE Ports: Port 1- Port 4 PoE Power Budget: 40 W Interfaces 6× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX External Power Supply External Power Adapter (Output: 53.5V/0.81A) Installation Desktop Wall Mount Standards and Protocols IEEE 802.3x Flow Control Data Rates 10/100 Mbps at Half Duplex 20/200 Mbps at Full Duplex Jumbo Frame 2 KB Mac Address Table 2K Max Power Consumption 1.87W(220 V / 50 Hz, no PD connected) 44.8W(220 V / 50 Hz, with 40W PD connected) Max Heat Dissipation 6.34 BTH/h (no PD connected) 152.32 BTH/h(with 40W PD connected) Hardware Package Contents • 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (MS106LP) • Power Adapter • Quick Installation Guide Environment Operating Temperature: 0?~40? (32?~104?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% RH non-condensing Storage Humidity: 5%~95% RH non-condensing Others
TP-LINK Switch 9x100Mbps (8xPOE+) Fémházas Asztali, LS109P
Telepítés • Asztali• Falra szerelés Felület • 9 × 10/100 Mbps RJ45 portok (8 × 10/100 Mbps 802.3af/PoE+ portoknál)• AUTOMATIKUS egyeztetés• AUTO MDI/MDIX Hálózati média • 10BASE-T: UTP kategória 3, 4, 5 kábel (maximum 100 m); EIA/TIA-568 100? STP (maximum 100m)• 100BASE-TX: UTP kategória 5, 5e kábel (maximum 100m); EIA/TIA-568 100? STP (maximum 100 m) Ventilátor mennyisége Ventilátor nélküli Tápegység Külső tápadapter (kimenet: 53,5 VDC / 1,31 A) PoE portok (RJ45) • Szabvány: 802.3 af/at kompatibilis• PoE portok: 1–8 portok, portonként akár 30 W PoE kimenet• Tápegység: 63 W LED kijelző • Tápellátás• Link/Act• PoE állapota• PoE MAX Méretek (Sz x Mé x Ma) 6,7 × 3,9 × 1,1 hüvelyk (171 × 98 × 27 mm) Maximális energiafogyasztás • 3,67 W (220 V/50 Hz, nincs PD csatlakoztatva)• 73,24 W (220 V/50 Hz, 63 W PD csatlakoztatva) Max hőleadás • 12,48 BTU/h (220 V/50 Hz nincs PD csatlakoztatva)• 249 BTU/h (220 V/50 Hz, 63 W PD csatlakoztatva) TELJESÍTMÉNY Kapcsolási kapacitás 1,8 Gbps Csomagtovábbítási sebesség 1,3392 Mpps MAC-cím táblázat 2K Jumbo Frame 1,5 KB SZOFTVER JELLEMZŐI Speciális funkciók • Extend Mode gomb (1–4/1–8 portok, 250 m-es PoE tápegység és adatátvitel)• Leválasztási mód gomb (1–8 portok)• PoE automatikus helyreállítási gomb (1–8 portok)• IEEE kompatibilis 802.3af/at kompatibilis PD-k• Mac-címek automatikus tanulása és automatikus öregítése• IEEE 802.3x Flow Control• Zöld technológia Átviteli módszer Tárolás-és-továbbítás EGYÉB Tanúsítvány CE, FCC, RoHS Csomag tartalma • LS109P• Tápadapter• Telepítési útmutató• Gumi lábak Környezet • Üzemi hőmérséklet: 0–40 ? (32–104 ?)• Tárolási hőmérséklet: -40–70 ? (-40–158 ?)• Üzemi páratartalom: 10–90% relatív páratartalom, nem lecsapódó• Tárolási páratartalom: 5–90% RH nem lecsapódó
TP-LINK Switch 6x1000Mbps(3xPOE+ + 1xPOE++) Fémházas Asztali, TL-SG1006PP
HARDVER JELLEMZŐK Felület • 6× 10/100/1000 Mbps RJ45 portok• AUTOMATIKUS egyeztetés• AUTO MDI/MDIX Hálózati média • 10BASE-T: UTP kategória 3, 4, 5 kábel (maximum 100 m)• EIA/TIA-568 100? STP (maximum 100 m)• 100BASE-TX: UTP kategória 5, 5e kábel (maximum 100 m)• EIA/TIA-568 100? STP (maximum 100m)• 1000BASE-T: UTP kategória 5, 5e, 6 vagy magasabb kábel (maximum 100m)• EIA/TIA-568 100? STP (maximum 100m) Ventilátor mennyisége Ventilátor nélküli Külső tápegység Külső tápadapter (kimenet: 53,5 VDC / 1,31 A) Csomagtovábbítási sebesség 8,928 Mpps PoE portok (RJ45) • Az 1. port megfelel a 802.3af/at/bt szabványnak; A 2-4 portok megfelelnek a 802.3af/atszabványnak • Tápegység: 64 W Mac címtáblázat 4K Kapcsolási kapacitás 12 Gbps Méretek (Sz x Mé x Ma) 6,2x4,0x1,0 hüvelyk (158x101x25 mm) Maximális energiafogyasztás • 4,75 W (220/50 Hz. PD nincs csatlakoztatva)• 71,46 W (220/50 Hz. 64 W PD csatlakoztatva) Max hőleadás • 16,20 BTU/h (220/50 Hz. nincs PD csatlakoztatva)• 243,68 BTU/h (220/50 Hz. 64 W PD csatlakoztatva) SZOFTVER JELLEMZŐI Speciális funkciók • Kompatibilis az IEEE 802.3af/at/bt kompatibilis PD-kkel• Mac-címek automatikus tanulása és automatikus öregítése• IEEE 802.3x Flow Control• 802.1p/DSCP QoS• IGMP Snooping• Mód kiterjesztés gomb (1-2-es portok, 250-ig) m PoE tápegység és adatátvitel)• PoE automatikus helyreállítás (1-4 portok) Átviteli módszer Tárolás-és-továbbítás EGYÉB Tanúsítvány FCC, CE, RoHS Csomag tartalma • TL-SG1006PP• Tápadapter• Telepítési útmutató Környezet • Üzemi hőmérséklet: 0–40 ? (32–104 ?);• Tárolási hőmérséklet: -40–70 ? (-40–158 ?)• Üzemi páratartalom: 10–90% relatív páratartalom, nem lecsapódó• Tárolási páratartalom: 5–90% relatív páratartalom, nem lecsapódó
TP-LINK Switch 10x1000Mbps (8xPOE+) Fémházas Asztali, LS1210GP
stallation • Desktop• Wall Mounting Interface • 9× 10/100/1000 Mbps RJ45 Ports (Ports 1–8 supports PoE+ output)• 1× Gigabit SFP Port Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100? STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100? STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100? STP (maximum 100m) Fan Quantity Fanless Physical Security Lock Yes Power Supply External Power Adapter(Output: 53.5VDC / 1.31A) PoE+ Ports(RJ45) • Standard: 802.3at/802.3af compliant• PoE Ports: Ports 1–8, up to 30 W PoE output per port• PoE Power Budget: 63W Dimensions ( W x D x H ) 8.2×4.9×1.0 in (209×126×26 mm) Max Power Consumption • 7.3 W (220/50Hz. no PD connected)• 76.96 W (220/50Hz. with 61 W PD connected) Max Heat Dissipation • 24.82 BTU/h (no PD connected)• 261.66 BTU/h (with 61 W PD connected) PERFORMANCE Switching Capacity 20 Gbps Packet Forwarding Rate 14.88 Mpps MAC Address Table 4K Jumbo Frame 16 KB SOFTWARE FEATURES Advanced Features • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission)• Isolation Mode Button (Ports 1–8)• PoE Auto Recovery Button (Ports 1–8)• Compatible With IEEE 802.3af/at Compliant PDs• IEEE802.3x Flow Control• 802.1p/DSCP QoS• IGMP Snooping• Green Technology Transmission Method Store-And-Forward OTHERS Certification CE, FCC, RoHS Package Contents • LS1210GP• Power Adapter• Installation Guide Environment Operating Temperature: 0°C~40°C (32°F~104°F)Storage Temperature: -40°C~70°C (-40°F~158°F)Operating Humidity: 10% ~ 90% non-condensingStorage Humidity: 5%~90% non-condensing
TP-LINK Switch 6x100Mbps (4xPOE) Fémházas Asztali, LS106LP
Telepítés • Asztali• Falra szerelés Felület • 6 × 10/100 Mbps RJ45 portok (4 × 10/100 Mbps 802.3af PoE portok)• AUTOMATIKUS egyeztetés• AUTO MDI/MDIX Hálózati média • 10BASE-T: UTP kategória 3, 4, 5 kábel (maximum 100 m); EIA/TIA-568 100? STP (maximum 100m)• 100BASE-TX: UTP kategória 5, 5e kábel (maximum 100m); EIA/TIA-568 100? STP (maximum 100 m) Ventilátor mennyisége Ventilátor nélküli Tápegység Külső tápadapter (kimenet: 53,5 VDC / 0,81 A) PoE portok (RJ45) • Szabvány: 802.3 af kompatibilis• PoE portok: 1–4 portok, portonként akár 15,4 W PoE kimenet• Tápegység: 41 W LED kijelző • Tápellátás• Link/Act• PoE állapota• PoE MAX Méretek (Sz x Mé x Ma) 6,2 × 4,0 × 1,0 hüvelyk (158 × 101 × 25 mm) Maximális energiafogyasztás • 2,53 W (220 V/50 Hz nincs PD csatlakoztatva)• 47,76 W (220 V/50 Hz, 41 W PD csatlakoztatva) Max hőleadás • 8,61 BTU/h (220 V/50 Hz, nincs PD csatlakoztatva)• 162,38 BTU/h (220 V/50 Hz, 41 W PD csatlakoztatva) TELJESÍTMÉNY Kapcsolási kapacitás 1,2 Gbps Csomagtovábbítási sebesség 0,8928 Mpps MAC-cím táblázat 2K Jumbo Frame 2 KB SZOFTVER JELLEMZŐI Speciális funkciók • Extend Mode gomb (1–4-es portok, 250 m-es PoE tápegység és adatátvitel)• PoE automatikus helyreállítási gomb (1–4-es portok)• IEEE 802.3af-kompatibilis PD-kkel kompatibilis• Mac-címek automatikus tanulása és automatikus öregítése• IEEE 802.3x Flow Control• Zöld technológia Átviteli módszer Tárolás-és-továbbítás EGYÉB Tanúsítvány CE, FCC, RoHS Csomag tartalma • LS106LP• Tápadapter• Telepítési útmutató Környezet • Üzemi hőmérséklet: 0–40 ? (32–104 ?)• Tárolási hőmérséklet: -40–70 ? (-40–158 ?)• Üzemi páratartalom: 10–90% relatív páratartalom, nem lecsapódó• Tárolási páratartalom: 5–90% RH nem lecsapódó
D-LINK Switch 24x1000Mbps (24xPOE) + 2xGigabit kombó SFP Fémházas Menedzselhető Rackes, DGS-1100-26MPV2/E
24x GE PoE Ports 2x GE/SFP Combo Ports 1 Smart Fan 525W
D-LINK Switch 16x1000Mbps + 2xGigabit SFP + 2xGigabit SFP+ Menedzselhető Rackes, DGS-1510-20/E
Technical Specifications: D-Link DGS-1510 Series Specifications DGS-1510-20 DGS-1510-28 DGS-1510-28P DGS-1510-28X DGS-1510-52 DGS-1510-52X General Port Standards & Functions IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, 802.3ae 10 GbE, IEEE 802.3x Flow Control for Full-Duplex Mode, Auto-negotiation Number of Ports: 10/100/1000 Mbps Gigabit SFP 10G SFP+ 16 2 2 24 2 2 24 2 2 24 - 4 48 2 2 48 - 4 Network Cables UTP Cat. 5, Cat. 5e (100 m max.) EIA/TIA-568 100-ohm STP (100 m max.) Full/Half Duplex Full/half duplex for 10/100 Mbps and Gigabit speed Media Interface Exchange Auto or configurable MDI/MDIX Performance Switching Capacity 76 Gbps 92 Gbps 92 Gbps 128 Gbps 140 Gbps 176 Gbps Transmission Method Store-and-forward MAC Address Table 16,000 entries per device MAC Address Update Up to 512 static MAC entries, Enable/disable auto-learning of MAC addresses Maximum 64 bytes Packet Forwarding Rate 56.54 Mpps 68.45 Mpps 68.45 Mpps 95.24 Mpp 104.16 Mpps 130.95 Mpps Packet Buffer Memory 1.5 MB per device 1.5 MB per device 1.5 MB per device 1.5 MB per device 3 MB per device 3 MB per device PoE PoE Standard - - IEEE 802.3af, 802.3at - - - PoE Capable Ports - - Ports 1 to 24: Up to 30 W - - - PoE Power Budget - - Max. 193 W - - - Physical & Environment AC Input 100 to 240 VAC 50/60 Hz internal universal power supply Maximum Power Consumption 20.3 W 24 W 238.7 W (PoE on), 29 W (PoE off) 22.3 W 38.4 W 44.2 W Standby Power Consumption 11.4 W / 100V 12.2 W / 240V 14.6 W / 100V 15.2 W / 240V 22.7 W / 100V 21.0 W / 240V 14.6 W / 100V 15.2 W / 240V 27.3 W / 100V 27.6 W / 240V 28.6 W / 100V 28.9 W / 240V Smart Fan Quantity 1 1 2 1 2 2 Acoustics 43.8 dB(A) 43.8 dB(A) 46.4 dB(A) 42.7 dB(A) 44.2 dB(A) 45.8 dB(A) Heat Dissipation 41.6 BTU/hr 72.3 BTU/hr 814.0 BTU/hr 76.0 BTU/hr 130.9 BTU/hr 138.8 BTU/hr Operation Temperature 23 to 122 °F (-5 to 50 °C) Storage Temperature -4 to 158 °F (-20 to 70°C) Operation Humidity 0% to 95% non-condensing Storage Humidity 0% to 95% non-condensing Dimensions 11 x 7.09 x 1.73 in. (280 x 180 x 44 mm) 19” standard rack mounting width, 1U height 17.36 x 8.26 x 1.73 in. (440 x 210 x 44 mm) 19” std rack mtg width 1U height 17.36 x 9.84 x 1.73 in. (440 x 250 x 44 mm) 19” std rack mtg width 1U height Weight 2.7 lbs (1.24 kg) 4.4 lbs (2.00 kg) 5.6 lbs (2.54 kg) 4.4 lbs (2.00 kg) 5.3 lbs (2.40 kg) 5.3 lbs (2.40 kg) Diagnostic LEDs Power/Stacking ID/Fan (per device), Link/Activity/Speed (per 10/100/1000 Mbps port), Link/ Activity/Speed (per Gigabit SFP port), Link/Activity/Speed (per 10G SFP+ port) Certifications CE, FCC, C-Tick, VCCI, BSMI, CCC Safety cUL, CB Software Features Stackability Virtual Stacking Support D-Link Single IP Management Up to 32 devices per virtual stack Physical Stacking Supports Duplex Chain/Ring topology Up to 40G stacking bandwidth full duplex Up to 6 units per stack L2 Features MAC Address Table: 16K Flow Control 802.3x Flow Control HOL Blocking Prevention Jumbo Frame up to 9000 Bytes IGMP Snooping IGMP v1/v2 Snooping IGMP v3 awareness Supports 512 IGMP groups Supports 128 static multicast addresses IGMP per VLAN Supports IGMP Snooping Querier Host-based IGMP Snooping Fast Leave MLD Snooping Supports MLD v1/v2 awareness Supports 512 groups Supports 128 Static Multicast Addresses Per VLAN MLD Snooping Host-based MLD Fast Leave MLD Snooping Querier Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.1s MSTP Loopback Detection 802.3ad Link Aggregation Max. 32 groups per device/8 ports per group Port Mirroring Support 4 mirroring groups One-to-One, Many-to-One Supports Mirroring for Tx/Rx/Both Multicast Filtering Forwards all unregistered groups Filters all unregistered groups LLDP, LLDP-MED VLAN 802.1Q Tagged VLAN 4K VLAN Groups Configurable VID: 0~4094 GVRP Asymmetric VLAN Auto Voice VLAN Auto Surveillance VLAN Quality of Service (QoS) 802.1p Quality of Service Queue Handling Strict Priority Queue (SPQ) Weighted Round Robin (WRR) Deficit Round Robin (DRR) SPQ + WRR 8 queues per port Bandwidth Control Port-based (Ingress/Egress, min. granularity for 10/100/1000 BASE-T ports is 64 Kb/s) CoS based on 802.1p priority VLAN MAC address Ether type IP address DSCP Protocol type TCP/UDP port number DSCP of IPv6 Traffic Class IPv6 flow label L3 Features ARP 256 Static ARP Supports Gratuitous ARP IPv6 Neighbour Discovery (ND) 8 IP Interfaces Default Routing Static Routing 64 IPv4 Static Route Entries 32 IPv6 Static Route Entries Access Control List (ACL) ACL based on 802.1p priority VLAN MAC address Ether type IP address DSCP Protocol type TCP/UDP port number DSCP of IPv6 Traffic Class IPv6 flow label Permit Deny Max. 256 access list Max. 768 rules Single or multiple ports (each rule) Time-based ACL ACL Statistics Security Port Security Supports up to 128 MAC addresses per port Broadcast/Multicast/Unicast Storm Control Dynamic ARP Inspection Static MAC D-Link Safeguard Engine DHCP Server Screening ARP Spoofing Prevention Max. 64 entries SSH Supports v2 Supports IPv4/IPv6 BPDU Attack Protection SSL Supports v1/v2/v3 Supports IPv4/IPv6 Traffic Segmentation IP-MAC-Port Binding DHCP snooping IP Source Guard Dynamic ARP inspection DHCPv6 Guard RA Guard IPv6 Snooping IPv6 Source Guard DoS Attack Prevention AAA Compound Authentication 802.1X Port and MAC-based Authentication Supports RADIUS and Local Server Supports EAP, OTP, TLS, TTLS, PEAP Web-based Access Control (WAC) Port-based Access Control Host-based Access Control Dynamic VLAN Assignment Guest VLAN MAC-based Access Control (MAC) Port-based Access Control Host-based Access Control Dynamic VLAN Assignment Japan Web-based Access Control (JWAC) Port-based Access Control Host-based Access Control Dynamic VLAN Assignment OAM Cable Diagnostics Factory Reset Management CLI Telnet Server TFTP Client IPv6 Neighbor Discovery Configurable MDI/MDIX SNMP Supports v1, v2c, v3 SNMP Trap System Log Max. 10,000 log entries DHCP Client D-Link Network Assistant support SNTP ICMPv6 IPv4/v6 Dual Stack DHCP Auto Configuration RMON v1 Debug Command Dual Image Web Based GUI D-Link Green 3.0 Technology Power Saving by: Link Status LED or Port Shutoff System Hibernation mode Time-based PoE (PoE model only)
D-LINK Switch 24x1000Mbps(24xPOE) + 2x10G + 2xGigabit SFP+ Menedzselhető Rackes, DGS-1520-28MP/E
Type Smart managed Number of ports 16 to 30 ports 48 to 54 ports Layer Layer 2 Layer 2+ Layer 3 Main type of ports 1000BASE-T Gigabit Ethernet 2.5GBASE-T Ethernet Type of uplink ports 10GBASE-T 10GbE SFP+ Switching capacity 128 Gbps 140 Gbps 188 Gbps PoE options 802.3af 802.3at Number of PoE ports 24 48 PoE power budget See datasheet See datasheet
TP-LINK Switch 16x1000Mbps(16xPOE+) + 2xGigabit SFP, Menedzselhető, TL-SG2218P
HARDWARE FEATURES Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x Interface • 16× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) • 2× Gigabit SFP Slots Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) • 1000BASE-X: MMF, SMF Fan Quantity 1 Power Supply 100-240V AC, 50/60Hz PoE Ports (RJ45) • Standard: 802.3at/af compliant • PoE+ Ports: 16 Ports • PoE Power Budget: 150 W* Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) Mounting Rack Mountable Max Power Consumption • 181.4 W (110 V/60 Hz) (with 150 W PD connected) • 178.3 W (220 V/50 Hz) (with 150 W PD connected) Max Heat Dissipation • 619.06 BTU/hr (110 V/60 Hz) (with 150 W PD connected) • 608.52 BTU/hr (220 V/50 Hz) (with 150 W PD connected) PERFORMANCE Switching Capacity 36 Gbps Packet Forwarding Rate 26.78 Mpps MAC Address Table 8K Packet Buffer Memory 4.1 Mbit Jumbo Frame 9 KB SOFTWARE FEATURES Quality of Service • 802.1p CoS/DSCP priority • 8 priority queues • Priority Schedule Mode - SP (Strict Priority) - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port/Flow based Rating Limit • Smoother Performance • Storm Control - Multiple Control Modes(kbps/ratio) - Broadcast/Multicast/Unknown-Unicast Control L2 and L2+ Features • 16 IP Interfaces - Support IPv4/IPv6 Interface • Static Routing - 32 IPv4/IPv6 Static Routes • DHCP Server • DHCP Relay - DHCP Interface Relay - DHCP VLAN Relay • DHCP L2 Relay • Static ARP • Proxy ARP • Gratuitous ARP • Link Aggregation - Static link aggregation - 802.3ad LACP - Up to 8 aggregation groups and up to 8 ports per group • Spanning Tree Protocol - 802.1D STP - 802.1w RSTP - 802.1s MSTP - STP Security: TC Protect, BPDU Filter/Protect, Root Protect • Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - CPU Mirroring - One-to-One - Many-to-One - Flow-Based - Ingress/Egress/Both • Device Link Detect Protocol (DLDP) • 802.1ab LLDP/ LLDP-MED VLAN • VLAN Group - Max. 4K VLAN Groups • 802.1Q tag VLAN • MAC VLAN: 12 Entries • Protocol VLAN • GVRP • Voice VLAN Access Control List • Support up to 230 entries • Time-Range - Time Slice - Week Time-Range - Absolute Time-Range - Holiday • Time-based ACL • MAC ACL - Source MAC - Destination MAC - VLAN ID - User Priority - Ether Type • IP ACL - Source IP - Destination IP - IP Protocol - TCP Flag - TCP/UDP Source Port - TCP/UDP Destination Port - DSCP/IP TOS • IPv6 ACL • Combined ACL • Rule Operation - Permit/Deny • Policy Action - Mirror - Rate Limit - Redirect - QoS Remark • ACL Rules Binding - Port Binding - VLAN Binding • Actions for flows - Mirror (to supported interface) - Redirect (to supported interface) - Rate Limit - QoS Remark Security • AAA • 802.1X - Port based authentication - MAC (Host) based authentication - Authentication Method includes PAP/EAP-MD5 - MAB - Guest VLAN - Support Radius authentication and accountability • IP/IPv6-MAC Binding - 512 Binding Entries - DHCP Snooping - DHCPv6 Snooping - ARP Inspection - ND Detection • IP Source Guard - 253 Entries - Source IP+Source MAC • IPv6 Source Guard - 183 Entries - Source IPv6 Address+Source MAC • DoS Defend • Static/Dynamic/Permanent Port Security - Up to 64 MAC addresses per port • Broadcast/Multicast/Unicast Storm Control - kbps/ratio control mode • Port Isolation • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure Command Line Interface (CLI) management with SSHv1/SSHv2 • IP/Port/MAC based access control IPv6 • IPv6 Static Routing and ACL • IPv6 Dual IPv4/IPv6 • IPv6 Interface • Multicast Listener Discovery (MLD) Snooping • IPv6 neighbor discovery (ND) • Path maximum transmission unit (MTU) discovery • Internet Control Message Protocol (ICMP) version 6 • TCPv6/UDPv6 • IPv6 applications - DHCPv6 Client - Ping6 - Tracert6 - Telnet(v6) - IPv6 SNMP - IPv6 SSH - IPv6 SSL - Http/Https - IPv6 TFTP Advanced Features • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule MIBs • MIB II (RFC1213) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIBs • RMON MIB(RFC1757, rmon 1,2,3,9) MANAGEMENT Omada App Yes, through • Omada Cloud-Based Controller • OC300 • OC200 • Omada Software Controller Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller OC300 • Omada Hardware Controller OC200 • Omada Software Controller Cloud Access Yes, through • Omada Cloud-Based Controller • OC300 • OC200 • Omada Software Controller Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller Management Features • Web-based GUI • Command Line Interface (CLI) through telnet • SNMPv1/v2c/v3 • SNMP Trap/Inform • RMON (1,2,3,9 groups) • SDM Template • DHCP/BOOTP Client • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • EEE • SNTP • System Log OTHERS Certification CE, FCC, RoHS Package Contents TL-SG2218P • Power Cord • Installation Guide • Rackmount Kit • Rubber Feet System Requirements Microsoft® Windows® XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. Environment • Operating Temperature: 0–50 ? (32–122 ?); • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
Huawei eKit Switch 24x1000Mbps (400W PoE+) + 4x1GE (SFP) + 1konzol port, S310-24P4S
First supported version V600R022C10 Integrated fixed device Y Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Weight without packaging [kg(lb)] 2.92 (6.44) Weight with packaging [kg(lb)] 3.79 (8.36) Typical power consumption [W] 40.07 Typical heat dissipation [BTU/hour] 136.72 Maximum power consumption [W] - Without PoE: 47.1 W - Full PoE load: 491.66 W (PoE: 400 W) Maximum heat dissipation [BTU/hour] - Without PoE: 160.71 - Full PoE load: 1677.59 Static power consumption [W] 30.82 100% power consumption [W] 40.54 MTBF [year] 60.18 MTTR [hour] 2 Availability >0.99999 Noise at normal temperature (acoustic power) [dB(A)] 49.3 Noise at high temperature (acoustic power) [dB(A)] 63 Noise at normal temperature (acoustic pressure) [dB(A)] 37.3 Number of card slots 0 Number of power slots 0 Number of fans modules 2 Maximum number of physical ports on the entire device 28 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 28 Maximum number of FE ports 24 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz Input voltage range [V] AC input: 90–290 V AC; 45–65 Hz Maximum input current [A] 6 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory 1 GB in total. To view the available flash memory size, run the display version command. Console port RJ45 Eth Management port Not supported USB Not supported Hardware real-time power detection Not supported Dying gasp Supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection [kV] Common mode: ±7 kV Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and front, air exhaustion from right PoE Supported Maximum PoE power consumption [W] 400 PoE+ power interfaces 24 PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) 24 Full load PoE power consumption 30W (802.3at) 13 Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 24x1000Mbps + 2x1GE (SFP), S110-24LP2SR
Integrated fixed device Y Dimensions without packaging (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 160.0 mm (1.72 in. x 17.40 in. x 6.30 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 167.0 mm (1.72 in. x 17.40 in. x 6.57 in.) Dimensions with packaging (H x W x D) 90.0 mm x 550.0 mm x 260.0 mm (3.54 in. x 21.65 in. x 10.24 in.) Chassis height 1 Installation type Rack mounting,Desk mounting,Wall mounting Weight without packaging 1.8 (3.97) Weight with packaging 2.3 (5.07) Typical power consumption 16 Typical heat dissipation 54.6 Maximum power consumption 17 Maximum heat dissipation 58 Static power consumption 5 100% power consumption 16 MTBF 76.10 MTTR 2 Availability >0.99999 Noise at normal temperature (acoustic power) Noise-free (no fans), < 30 Noise at high temperature (acoustic power) Noise-free (no fans), < 30 Noise at normal temperature (acoustic pressure) Noise-free (no fans), < 20 Number of card slots 0 Number of power slots 0 Number of fans modules 0 Maximum number of physical ports on the entire device 26 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 26 Maximum number of FE ports 26 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) Restriction on the operating temperature variation rate When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity 5% RH to 95% RH (non-condensing) Long-term operating altitude 0–5000 m (0–16404 ft.) Storage altitude 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage AC input: 100–240 V AC; 50/60 Hz Input voltage range AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz Maximum input current 0.8 A CPU - Memory - Flash memory - Console port Not supported Eth Management port Not supported USB Not supported Hardware real-time power detection Not supported Dying gasp Not supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection Common mode: ±1 kV Power supply surge protection Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans None Heat dissipation mode Natural heat dissipation Airflow direction - PoE Not supported Maximum PoE power consumption - PoE+ power interfaces - PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) - Full load PoE power consumption 30W (802.3at) - Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 48x1000Mbps + 4x10GE (SFP+) + 1konzol port, S220-48T4X
First supported version V600R023C00 Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Chassis material Metal Weight without packaging [kg(lb)] 2.71 (5.97) Weight with packaging [kg(lb)] 3.59 (7.91) Typical power consumption [W] 36.95 Typical heat dissipation [BTU/hour] 126.07 Maximum power consumption [W] 44.3 Maximum heat dissipation [BTU/hour] 151.15 Static power consumption [W] 18.8 100% power consumption [W] 36.95 MTBF [year] 40.61 MTTR [hour] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 46.6 Noise at high temperature (acoustic power) [dB(A)] 54.3 Noise at normal temperature (acoustic pressure) [dB(A)] 34.6 Number of fans modules 1 Maximum number of physical ports on the entire device 52 Maximum number of GE ports 52 Maximum number of FE ports 48 Uplink ports 4 x 10GE SFP+ ports Downlink ports 48 x 10/100/1000BASE-T ports Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). The operating temperature ranges from –5°C (23°F) to +45°C (113°F) when optical modules with transmission distances greater than or equal to 60 km are used. The device does not support dying gasp when the ambient temperature is higher than 40°C (104°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz Input voltage range [V] AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz Maximum input current [A] 1.6 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory Physical space: 1 GB Console port RJ45 Eth Management port Not supported USB Not supported Service port surge protection [kV] Common mode: ±7 kV Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and air exhaust from right PoE Not supported Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 48x1000Mbps + 4x1GE (SFP) + 1konzol port, S220-48T4S
First supported version V600R023C00 Integrated fixed device Y Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Chassis material Metal Weight without packaging [kg(lb)] 2.71 (5.97) Weight with packaging [kg(lb)] 3.59 (7.91) Typical power consumption [W] 36.15 Typical heat dissipation [BTU/hour] 123.35 Maximum power consumption [W] 43.3 Maximum heat dissipation [BTU/hour] 147.74 Static power consumption [W] 18.8 100% power consumption [W] 36.15 MTBF [year] 40.61 MTTR [hour] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 46.6 Noise at high temperature (acoustic power) [dB(A)] 54.3 Noise at normal temperature (acoustic pressure) [dB(A)] 34.6 Number of fans modules 1 Maximum number of physical ports on the entire device 52 Maximum number of GE ports 52 Maximum number of FE ports 48 Uplink ports 4 x GE SFP ports Downlink ports 48 x 10/100/1000BASE-T ports Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). The operating temperature ranges from –5°C (23°F) to +45°C (113°F) when optical modules with transmission distances greater than or equal to 60 km are used. The device does not support dying gasp when the ambient temperature is higher than 40°C (104°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz Input voltage range [V] AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz Maximum input current [A] 1.6 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory Physical space: 1 GB Console port RJ45 Eth Management port Not supported USB Not supported Service port surge protection [kV] Common mode: ±7 kV Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and air exhaust from right PoE Not supported Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 24x1000Mbps + 2x1GE (SFP), PoE+, S110-24LP2SR
Integrated fixed device Y Dimensions without packaging (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 260.0 mm (1.72 in. x 17.40 in. x 10.24 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 267.0 mm (1.72 in. x 17.40 in. x 10.51 in.) Dimensions with packaging (H x W x D) 90.0 mm x 555.0 mm x 400.0 mm (3.54 in. x 21.85 in. x 15.75 in.) Chassis height 1 Installation type Rack mounting,Desk mounting,Wall mounting Weight without packaging 3.2 (7.05) Weight with packaging 3.7 (8.16) Typical power consumption 24 Typical heat dissipation 81.89 Maximum power consumption Without PoE: 24 W Full PoE load: 165 W (PoE: 124 W) Maximum heat dissipation Without PoE: 81.89 Full PoE load: 563 Static power consumption 13 100% power consumption 24 MTBF 42.92 MTTR 2 Availability >0.99999 Noise at normal temperature (acoustic power) Noise-free (no fans), < 30 Noise at high temperature (acoustic power) Noise-free (no fans), < 30 Noise at normal temperature (acoustic pressure) Noise-free (no fans), < 20 Number of card slots 0 Number of power slots 0 Number of fans modules 0 Maximum number of physical ports on the entire device 26 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 26 Maximum number of FE ports 26 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) Restriction on the operating temperature variation rate When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity 5% RH to 95% RH (non-condensing) Long-term operating altitude 0–5000 m (0–16404 ft.) Storage altitude 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage AC input: 100–240 V AC; 50/60 Hz Input voltage range AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz Maximum input current 3 A CPU - Memory - Flash memory - Console port Not supported Eth Management port Not supported USB Not supported Hardware real-time power detection Not supported Dying gasp Not supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection Common mode: ±4 kV Power supply surge protection Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans None Heat dissipation mode Natural heat dissipation Airflow direction - PoE Supported Maximum PoE power consumption 124 PoE+ power interfaces 24 PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) 8 Full load PoE power consumption 30W (802.3at) 4 Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 48x1000Mbps (380 W, PoE+) + 4x1GE (SFP) + 1konzol port, S220-48P4S
First supported version V600R023C00 Integrated fixed device Y Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Chassis material Metal Weight without packaging [kg(lb)] 3.24 (7.14) Weight with packaging [kg(lb)] 4.29 (9.46) Typical power consumption [W] 48.64 Typical heat dissipation [BTU/hour] 165.96 Maximum power consumption [W] - Without PoE: 63.70 W - Full PoE load: 462.80 W (PoE: 380 W) Maximum heat dissipation [BTU/hour] - Without PoE: 217.35 - Full PoE load: 1579.12 Static power consumption [W] 34.04 100% power consumption [W] 48.64 MTBF [year] 48.14 MTTR [hour] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 49.3 Noise at high temperature (acoustic power) [dB(A)] 63 Noise at normal temperature (acoustic pressure) [dB(A)] 37.3 Number of fans modules 2 Maximum number of physical ports on the entire device 52 Maximum number of GE ports 52 Maximum number of FE ports 48 Uplink ports 4 x GE SFP ports Downlink ports 48 x 10/100/1000BASE-T ports (380 W, PoE+) Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). The operating temperature ranges from –5°C (23°F) to +45°C (113°F) when optical modules with transmission distances greater than or equal to 60 km are used. Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] - AC input: 100 V AC to 240 V AC, 50/60 Hz - High-voltage DC input: 240 V DC Input voltage range [V] - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz - High-voltage DC input: 190 V DC to 290 V DC Maximum input current [A] 6 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory Physical space: 1 GB Console port RJ45 Eth Management port Not supported USB Not supported Dying gasp Supported Service port surge protection [kV] Common mode: ±7 kV Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and air exhaust from right PoE Supported Maximum PoE power consumption [W] 380 PoE+ power interfaces 48 Full load PoE power consumption 15.4W (802.3af) 24 Full load PoE power consumption 30W (802.3at) 12 Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Engine Gateway 1x1000Mbps (WAN) + 4x1000Mbps (PoE+), Menedzselhető, Asztali, S380-L4P1T
First supported version V600R022C10 Integrated fixed device Y Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 35.0 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 35.0 mm x 210.0 mm x 136.3 mm (1.38 in. x 8.27 in. x 5.37 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 285.0 mm x 180.0 mm (3.54 in. x 11.22 in. x 7.09 in.) Chassis height [U] 0.8 Installation type Desk mounting,Wall mounting Weight without packaging [kg(lb)] 0.9 (1.98) Weight with packaging [kg(lb)] 1.1 (2.43) Typical power consumption [W] 7.19 Typical heat dissipation [BTU/hour] 24.5 Maximum power consumption [W] 61.65 W (PoE: 50 W) Maximum heat dissipation [BTU/hour] 210.4 Static power consumption [W] 4.54 100% power consumption [W] 7.35 MTBF [year] 75.89 MTTR [hour] 2 Availability >0.99999 Noise at normal temperature (acoustic power) [dB(A)] Noise-free (no fans), < 30 Noise at high temperature (acoustic power) [dB(A)] Noise-free (no fans), < 30 Noise at normal temperature (acoustic pressure) [dB(A)] Noise-free (no fans), < 20 Number of card slots 0 Number of power slots 0 Number of fans modules 0 Maximum number of physical ports on the entire device 5 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 5 Maximum number of FE ports 5 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode Power adapter Rated input voltage [V] Power adapter input: 100–240 V AC; 50/60 Hz Power adapter output: 56 V DC Input voltage range [V] Power adapter input: 90–290 V AC; 47–63 Hz Maximum input current [A] 1.07 A CPU Quad-core, 800 MHz Memory DDR4: 512 MB Flash memory NAND Flash: 512 MB Storage - Console port Not supported Eth Management port LAN port USB Not supported Hardware real-time power detection Not supported Dying gasp Not supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection [kV] Common mode: ±4 kV Power supply surge protection [kV] Power adapter: ±6 kV in differential mode and ±6 kV in common mode Ingress protection level (dustproof/waterproof) IP20 Types of fans None Heat dissipation mode Natural heat dissipation Airflow direction - PoE Supported Maximum PoE power consumption [W] 50 W PoE+ power interfaces 4 PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) 3 Full load PoE power consumption 30W (802.3at) 1 Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 16x1000Mbps + 2x1GE (SFP), PoE+, S110-16LP2SR
Integrated fixed device Y Dimensions without packaging (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 260.0 mm (1.72 in. x 17.40 in. x 10.24 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 267.0 mm (1.72 in. x 17.40 in. x 10.51 in.) Dimensions with packaging (H x W x D) 90.0 mm x 555.0 mm x 400.0 mm (3.54 in. x 21.85 in. x 15.75 in.) Chassis height 1 Installation type Rack mounting,Desk mounting,Wall mounting Weight without packaging 3.0 (6.61) Weight with packaging 3.7 (8.16) Typical power consumption 22.0 Typical heat dissipation 75.07 Maximum power consumption Without PoE: 22.0 W Full PoE load: 160.0 W (PoE: 124 W) Maximum heat dissipation Without PoE: 75.07 Full PoE load: 545.94 Static power consumption 12.0 100% power consumption 22.0 MTBF 57.77 MTTR 2 Availability >0.99999 Noise at normal temperature (acoustic power) Noise-free (no fans), < 30 Noise at high temperature (acoustic power) Noise-free (no fans), < 30 Noise at normal temperature (acoustic pressure) Noise-free (no fans), < 20 Number of card slots 0 Number of power slots 0 Number of fans modules 0 Maximum number of physical ports on the entire device 18 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 18 Maximum number of FE ports 18 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) Restriction on the operating temperature variation rate When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity 5% RH to 95% RH (non-condensing) Long-term operating altitude 0–5000 m (0–16404 ft.) Storage altitude 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage AC input: 100–240 V AC; 50/60 Hz Input voltage range AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz Maximum input current 3 A CPU - Memory - Flash memory - Console port Not supported Eth Management port Not supported USB Not supported Hardware real-time power detection Not supported Dying gasp Not supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection Common mode: ±4 kV Power supply surge protection Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans None Heat dissipation mode Natural heat dissipation Airflow direction - PoE Supported Maximum PoE power consumption 124 PoE+ power interfaces 16 PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) 8 Full load PoE power consumption 30W (802.3at) 4 Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
