ZYXEL XS1930-12HP-ZZ0101F ZYXEL Switch 10x10Gpbs (8xPOE) + 2xGigabit SFP+, Menezdselhető Rackes, XS1930-12HP-ZZ0101F
XS1930-10 XS1930-12HP Leírás Termék neve 8-port Multi-Gigabit Smart Menedzselt Switch with 2 SFP+ Uplink 8-port Multi-Gigabit Smart Menedzselt PoE Switch 2 10GbE és 2 SFP+ Uplink Switch osztály Smart menedzselt Smart menedzselt Port sűrűség Portok száma 10 12 100M/1G/2.5G/5G/10G Ethernet (RJ-45) 8 10 10-Gigabit SFP+ 2 2 PoE PoE portok - 8 Total PoE budget (watt szerint) - 375 IEEE 802.3bt (PoE++) - Yes Teljesítmény Switching kapacitás (Gbps) 200 240 Továbbítási arány (Mpps) 148.8 178.5 Packet buffer (byte) 2 MB 2 MB MAC address table 16 K 16 K L3 továbbító lap Max. 512 IPv4 belépő; Max. 512 IPv4 belépő Max. 512 IPv4 belépő; Max. 512 IPv4 belépő Routing table 32 32 IP interfész 32/32 32/32 Flash/RAM 32 MB/256 MB 32 MB/256 MB Erőforrás igény Input 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz Max. energiaigény (watt) 44.3 493 Fizikai specifikációk Elem Méretek (WxDxH)(mm/in.): 330 x 230 x 44/12.99 x 9.06 x 1.73 Súly (kg/lb.): 2.4/5.29 Méretek (WxDxH)(mm/in.): 330 x 230 x 44/12.99 x 9.06 x 1.73 Súly (kg/lb.): 2.8/6.17 Csomagolás Méretek (WxDxH)(mm/in.): 484 x 337 x 79/19.06 x 13.27 x 3.11 Súly (kg/lb.): 3.5/7.72 Méretek (WxDxH)(mm/in.): 484 x 337 x 79/19.06 x 13.27 x 3.11 Súly (kg/lb.): 4.0/8.82 Tartalmazott kiegészítők Tápkábel Rack szerelőkészlet Környezeti specifikációk Működés Hőmérséklet -20°C-tól 50°C-ig/-4°F-tól 122°F-ig Nedvesség 5%-tól 95%-ig (nem cseppfolyós) Tárolás Hőmérséklet -40°C-től 70°C-ig/-40°F-től 158°F-ig Nedvesség 5%-tól 95%-ig (nem cseppfolyós) MTBF (hr) 778,690 582,873 Hőelvezetés (BTU/hr) 151.06 1,681.13 Akusztikus zaj (min/max, dBA) 28/50 28.3/50.8
Huawei eKit Switch 8x1000Mbps (POE+) + 1x1GbE + 1x1GE (SFP), Nem menedzselhető, Asztali, S110-8P2ST
Integrated fixed device Y Dimensions without packaging (H x W x D) Basic dimensions (excluding the parts protruding from the body): 35 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 36.5 mm x 210.0 mm x 131.7 mm (1.44 in. x 8.27 in. x 5.19 in.) Dimensions with packaging (H x W x D) 150.0 mm x 270.0 mm x 200.0 mm (5.91 in. x 10.63 in. x 7.87 in.) Chassis height 0.8 Installation type Desk mounting,Wall mounting Weight without packaging 1.11 (2.45) Weight with packaging 1.46 (3.22) Typical power consumption 11 Typical heat dissipation 37.53 Maximum power consumption Without PoE: 11 W Full PoE load: 155 W (PoE: 124 W) Maximum heat dissipation - Without PoE: 37.53 - Full PoE load: 528.88 Static power consumption 3 100% power consumption 11 MTBF 78.77 MTTR 2 Availability >0.99999 Noise at normal temperature (acoustic power) Noise-free (no fans), < 30 Noise at high temperature (acoustic power) Noise-free (no fans), < 30 Noise at normal temperature (acoustic pressure) Noise-free (no fans), < 20 Number of card slots 0 Number of power slots 0 Number of fans modules 0 Maximum number of physical ports on the entire device 10 Maximum number of 100GE ports 0 Maximum number of 40GE ports 0 Maximum number of 25GE ports 0 Maximum number of 10GE ports 0 Maximum number of 5GE ports 0 Maximum number of 2.5GE ports 0 Maximum number of GE ports 10 Maximum number of FE ports 10 Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) Restriction on the operating temperature variation rate When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity 5% RH to 95% RH (non-condensing) Long-term operating altitude 0–5000 m (0–16404 ft.) Storage altitude 0-5000 m (0-16404 ft.) Power supply mode Power adapter Rated input voltage Power adapter input: 170–240 V AC; 50/60 Hz Power adapter output: 56 V DC Input voltage range Power adapter input: 170–264 V AC; 47–63 Hz Maximum input current 2.68 A CPU - Memory - Flash memory - Console port Not supported Eth Management port Not supported USB Not supported Hardware real-time power detection Not supported Dying gasp Not supported RTC Not supported RPS input Not supported Complete device sleeping Not supported Service port surge protection Common mode: ±4 kV Power supply surge protection Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans None Heat dissipation mode Natural heat dissipation Airflow direction - PoE Supported Maximum PoE power consumption 124 PoE+ power interfaces 8 PoE++ power interfaces - Full load PoE power consumption 15.4W (802.3af) 8 Full load PoE power consumption 30W (802.3at) 4 Full load PoE++ power consumption 60W (802.3bt) - Full load PoE++ power consumption 90W (802.3bt) - Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 24x1000Mbps (400 W, PoE+) + 4x10GE (SFP+) + 1konzol port, S220-24P4X
First supported version V600R023C00 Integrated fixed device Y Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Chassis material Metal Weight without packaging [kg(lb)] 2.92 (6.44) Weight with packaging [kg(lb)] 3.79 (8.36) Typical power consumption [W] 37.12 Typical heat dissipation [BTU/hour] 126.65 Maximum power consumption [W] - Without PoE: 44.35 W - Full PoE load: 485.91 W (PoE: 400 W) Maximum heat dissipation [BTU/hour] - Without PoE: 151.32 - Full PoE load: 1657.92 Static power consumption [W] 27.07 100% power consumption [W] 37.12 MTBF [year] 60.18 MTTR [hour] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 49.3 Noise at high temperature (acoustic power) [dB(A)] 63 Noise at normal temperature (acoustic pressure) [dB(A)] 37.3 Number of fans modules 2 Maximum number of physical ports on the entire device 28 Maximum number of 10GE ports 4 Maximum number of 2.5GE ports 0 Maximum number of GE ports 28 Maximum number of FE ports 24 Uplink ports 4 x 10GE SFP+ ports Downlink ports 24 x 10/100/1000BASE-T ports (400 W, PoE+) Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] - AC input: 100 V AC to 240 V AC, 50/60 Hz - High-voltage DC input: 240 V DC Input voltage range [V] - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz - High-voltage DC input: 190 V DC to 290 V DC Maximum input current [A] 6 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory Physical space: 1 GB Console port RJ45 Eth Management port Not supported USB Not supported Service port surge protection [kV] Common mode: ±7 kV Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and front, air exhaustion from right PoE Supported Maximum PoE power consumption [W] 400 PoE+ power interfaces 24 Full load PoE power consumption 15.4W (802.3af) 24 Full load PoE power consumption 30W (802.3at) 13 Certification EMC certification Safety certification Manufacturing certification
Huawei eKit Switch 24x1000Mbps + 4x10GE (SFP+) + 1konzol port, S220-24T4X
S220-24T4X (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, built-in AC power) Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Chassis material Metal Weight without packaging [kg(lb)] 2.32 (5.11) Weight with packaging [kg(lb)] 3.44 (7.58) Typical power consumption [W] 27.27 Typical heat dissipation [BTU/hour] 93.05 Maximum power consumption [W] 35.04 Maximum heat dissipation [BTU/hour] 119.56 Static power consumption [W] 19.00 100% power consumption [W] 27.27 MTBF [year] 70.75 MTTR [hour] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 47 Noise at high temperature (acoustic power) [dB(A)] 51 Noise at normal temperature (acoustic pressure) [dB(A)] 35 Number of fans modules 1 Maximum number of physical ports on the entire device 28 Maximum number of FE ports 24 Uplink ports 4 x 10GE SFP+ ports Downlink ports 24 x 10/100/1000BASE-T ports Dedicated stack port Not supported Redundant power supply Not supported Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz Input voltage range [V] AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz Maximum input current [A] 0.8 A CPU 1.1 GHz, 2 cores Memory 2 GB Flash memory Physical space: 1 GB Console port RJ45 Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and front, air exhaustion from right PoE Not supported Maximum number of 10GE ports 4 Maximum number of GE ports 28 Eth Management port Not supported USB Not supported Service port surge protection [kV] Common mode: ±7 kV
D-LINK DGS-1210-10/E 8x1000Mbps + 2xGigabit SFP Menedzselhető Rackes Switch
Technical Specifications: D-Link DGS-1210 Specificatins DGS-1210-10 DGS-1210-20 DGS-1210-28 DGS-1210-52 General Number of Ports 8 10/100/1000 Mbps 2 SFP 16 10/100/1000 Mbps 4 SFP 24 10/100/1000 Mbps 4 SFP 48 10/100/1000 Mbps 4 SFP Port Standard & Functions IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX (Fast Ethernet) IEEE 802.3ab 1000BASE-T (Gigabit Ethernet) IEEE 802.3x Flow Control for Full-Duplex Mode Auto-negotiation Network Cables UTP Cat. 5, Cat. 5e (100 m max.) EIA/TIA-568 100-ohm STP (100 m max.) Full/Half Duplex Full/half duplex for 10/100 Mbps speeds Full duplex for Gigabit speed Media Interface Exchange Auto or configurable MDI/MDIX Performance Switching Capacity 20 Gbps 40 Gbps 56 Gbps 104 Gbps Transmission Method Store-and-forward MAC Address Table 16,000 entries per device MAC Address Update Up to 256 static MAC entries Enable/disable auto-learning of MAC addresses Maximum 64 bytes packet forwarding rate 14.88 Mpps 29.8 Mpps 41.7 Mpps 77.4 Mpps Packet Buffer Memory 1.5 MB 1.5 MB 1.5 MB 3.0 MB Physical & Environmental AC Input 100 to 240 VAC 50/60 Hz internal universal power supply Maximum Power Consumption 13.59 W 16.09 W 22.45 W 38.27 W Standy Power Consumption 9.3 W/110 V, 9.4 W/240 V 8.59 W/110 V, 8.80 W/240 V 17.65 W/110 V, 17.84 W/240 V 29.44 W/110 V, 29.49 W/240 V Fan Quantity 0 0 0 Two smart fans Acoustics 0 dB(A) 0 dB(A) 0 dB(A) Low speed: 39.8 dB(A) High speed: 49.2 dB(A) Heat Dissipation 46.37 BTU/hr 54.91 BTU/hr 76.55 BTU/hr 130.58 BTU/hr Operating Temperature 23 to 122 °F (-5 to 50 °C) Storage Temperature -4 to 158 °F (-20 to 70°C) Operating Humidity 0% to 95% non-condensing Storage Humidity 0% to 95% non-condensing Dimensions (W x D x H) 11.02 x 4.96 x 1.73 inches (280 x 126 x 44 mm) • 19” standard rack mounting width, 1U height 11.02 x 7.09 x 1.73 inches (280 x 180 x 44 mm) 19” standard rack mounting width, 1U height 17.32 x 5.51 x 1.73 inches (440 x 140 x 44 mm) 19” standard rack mounting width, 1U height 17.32 x 8.27 x 1.73 inches (440 x 210 x 44 mm) 19” standard rack mounting width, 1U height Weight 3.39 lbs (1.54 kg) 2.82 lbs (1.28 kg) 3.68 lbs (1.67 kg) 5.69 lbs (2.58 kg) Diagnostic LEDs Power (per device) Link/Activity/Speed (per 10/100/1000 Mbps port) Link/Activity/Speed (per SFP port) Power (per device) Link/Activity/Speed (per 10/100/1000 Mbps port) Link/Activity/Speed (per SFP port) Fan (per device) MTBF 360,844 hours 317,412 hours 540,000 hours 481,624 hours Certifications FCC Class A CE Class A ICES-003 VCCI Class A C-Tick BSMI Safety cUL CE LVD Software Features L2 Features MAC Address Table 16,000 entries Flow Control 802.3x Flow Control HOL Blocking Prevention IGMP Snooping IGMP v1/v2 Snooping Supports 256 IGMP groups Supports at least 64 static multicast addresses IGMP per VLAN Supports IGMP Snooping Querier Loopback Detection Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.3ad Link Aggregetion DGS-1210 28/28P: Maximum of 14 groups/8 ports per group DGS-1210 52/52MP: Maximum of 26 groups/8 ports per group DGS-1210 -10/10P: Maximum of 5 groups/8 ports per group LLDP LLDP-MED Jumbo Frame Up to 9,216 bytes Spanning Tree Protocol 802.1D STP 802.1w RSTP Flow Control 802.3x Flow Control HOL Blocking Prevention Port Mirroring One-to-One Many-to-One Supports Mirroring for Tx/Rx/Both Multicast Filtering Forwards all unregistered groups Filters all unregistered groups Configurable MDI/MDIX MLD snooping v1/v2 (256 groups) VLAN 802.1Q VLAN Group Max 256 static VLAN groups Max 4094 VIDs Management VLAN Asymmetric VLAN Auto Voice VLAN Max. 10 user defined OUI Max. 8 default OUI Auto Surveillance VLAN QoS (Quality of Service) 802.1p Quality of Service 8 Queues per port Queue Handling Strict Weighted Round Robin (WRR) Bandwidth Control Port-based (Ingress/Egress, min. granularity 64 Kb/s) QoS based on: 802.1p Priority Queues DSCP ToS IPv6 Traffic Class TCP/UDP port L3 Features IP Interface Supports 1 interface IPv6 Neighbor Discovery (ND) Access Control List Max. 50 access list Max. 768 rules shared by IPv4, MAC and IPv6 Each rule can only be associated with a single port ACL based on 802.1p priority VLAN MAC address Ether type IP address DSCP Protocol type TCP/UDP port number IPv6 Traffic Class Security Broadcast/Multicast/Unicast Storm Control D-Link Safeguard Engine DHCP Server Screening IP-MAC-Port Binding (Smart Binding) Supports 512 address binding entries ARP Inspection ARP + IP Inspection Supports DHCP Snooping 802.1X Port-based Access Control ARP Spoofing Prevention Max. 64 entries Traffic Segmentation SSH v2 SSL Supports v1/v2/v3 Port Security Supports up to 64 MAC addresses per port Duplicate address detection AAA 802.1X Authentication Supports local/RADIUS database Supports port-based access control Supports EAP, OTP, TLS, TTLS, PEAP IPv6 RADIUS Server Support MD5 authentication OAM Cable Diagnostics Factory Reset MIB/RFC Standards RFC 783 TFTP RFC 951 BootP/DHCP Client RFC 1157 SNMP v1, v2, v3 RFC 1213 MIB II RFC 1215 MIB Traps Convention RFC 1350 TFTP RFC 1493 Bridge MIB RFC 1769 SNTP RFC 1542 BootP/DHCP Client RFC 1901 SNMP v1, v2, v3 RFC 1907 SNMP v2 MIB RFC 1908 SNMP v1, v2, v3 RFC 2131 BootP/DHCP Client RFC 2138 RADIUS Authentication RFC 2139 RADIUS Authentication RFC 2233 Interface Group MIB RFC-2246 SSL RFC 2475 RFC 2570 SNMP v1, v2, v3 RFC 2575 SNMP v1, v2, v3 RFC 2598 CoS RFC 2618 RADIUS Authentication RFC 2819 RMON v1 RFC 2865 RADIUS Authentication RFC 3164 System Log RFC 3195 System Log RFC 3411-17 SNMP D-Link Private MIB LLDP MIB Zone Defense MIB 2233 Interface Group MIB Management Web-based GUI D-Link Network Assistant Utility Compact CLI Telnet Server TFTP Client Configurable MDI/MDIX SNMP Supports v1/v2c/v3 SNMP Trap Backup/Upgrade firmware Smart Wizard Upload/Download Configuration file System Log Max. 500 log entries BootP/DHCP Client SNTP ICMP v6 IPv4/v6 Dual Stack DHCP Auto Configuration Time Setting SNTP RMONv1 Trusted Host D-Link Green 3.0 Technology Power Saving by: Link Status Time-based PoE: PoE ports can be turned on/off by port or system through schedule LED Shutoff System Hibernation Port Shutoff
TP-LINK DS108G-M2 Omada 8-Port 2.5G Multi-Gigabit Unmanaged Desktop Switch
Omada 8-Port 2.5G Multi-Gigabit Desktop Switch PORT: 8× 2.5G RJ45 Ports SPEC: Desktop Steel Case FEATURE: Plug and Play
TP-LINK LS105LP 5-Port 10/100Mbps Desktop Switch with 4-Port PoE
5-Port 10/100 Mbps Desktop Switch with 4-Port PoE PORT: 4× 10/100 Mbps PoE Ports, 1× 10/100 Mbps Non-PoE Port SPEC: 802.3af, 41 W PoE Power, Desktop Steel Case FEATURE: Extend Mode for 250m PoE Transmitting, PoE Auto Recovery, Plug and Play
TP-LINK SG3428X Omada 24-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots
Omada 24-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots PORT: 24× Gigabit RJ45 Ports, 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller, Static Routing, OAM, sF
LINKEASY ipari switch, 5x10/100/1000BaseTX, duál DC10~58V bemenet, DIN sín, -40~+85C
Menedzselhetőség Nem menedzselhető Rögzítés DIN sín Üzemi hőmérséklet tartomány -40°C - 85°C PoE teljesítmény Nem PoE Fast Ethernet interfész Nincs Gigabit Ethernet interfész 5x10/100/1000Base-T Optikai interfész Nincs Combo interfész Nincs Bővítési lehetőség Nincs Tápfeszültség 10-58VDC Egyéb interfész Nincs Tápellátás 12/24/48VDC
TP-LINK Switch 5x1000Mbps(1xPOE++/4xPOE+) Kültéri Műanyagházas (Omada), SG2005P-PD
HARDVER JELLEMZŐK Szabványok és protokollok IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x Csatlakozások • 1× 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt)• 4× 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at PoE) Hálózati összeköttetés • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)• 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) Ventilátorok száma Fanless Hálózati tápegység Obtain Power from 802.3af/at/bt PoE Source PoE portok (RJ45) • PoE In Port: Port 5, Compliance with 802.3af/at/bt• PoE Out Ports: Ports 1-4, compliance with 802.3af/at PoE• PoE Power Budget:-64 W when powered by 802.3bt Type 4 (90 W)-44 W when powered by 802.3bt Type 3 (60 W)-19 W when powered by 802.3at-6 W when powered by 802.3af Méretek (Sz x Mé x Ma) 3.9 × 1.5 × 6.7 in (100 × 38.5 × 170 mm) Max. áramfelvétel 71.5 W (when powered by 802.3bt Type 4 (90 W)) Max Heat Dissipation 243.99 BTU/hr (when powered by 802.3bt Type 4 (90 W)) MŰKÖDÉSI JELLEMZŐK Switching teljesítmény 10 Gbps Csomagtovábbítási sebesség 7.44 Mpps Fizikai (MAC) cím tábla 8k Csomag puffer memória 4.1 Mbit Jumbo Frame 9 KB SZOFTVER JELLEMZŐK QoS (szolgáltatás minősége) • 802.1p CoS/DSCP priority• 8 priority queues• Priority Schedule Mode- SP (Strict Priority)- WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control- Port/Flow-based Rating Limit• Smoother Performance• Storm Control- Multiple Control Modes(kbps/ratio)- Broadcast/Multicast/Unknown-Unicast Control L2 és L2+ jellemzők • 16 IP Interfaces- Support IPv4/IPv6 Interface• Static Routing- 32 IPv4/IPv6 Static Routes• DHCP Server• DHCP Relay- DHCP Interface Relay- DHCP VLAN Relay• DHCP L2 Relay• Static ARP• Proxy ARP• Gratuitous ARP• Link Aggregation- Static link aggregation- 802.3ad LACP- Up to 8 aggregation groups and up to 8 portsper group• Spanning Tree Protocol- 802.1D STP- 802.1w RSTP- 802.1s MSTP- STP Security: TC Protect, BPDU Filter/Protect,Root Protect• Loopback Detection• Flow Control- 802.3x Flow Control• Mirroring- Port Mirroring- CPU Mirroring- One-to-One- Many-to-One- Flow-Based- Ingress/Egress/Both• Device Link Detect Protocol (DLDP)• 802.1ab LLDP/ LLDP-MED L2 Multicast • 511 IPv4, IPv6 shared multicast groups• IGMP Snooping- IGMP v1/v2/v3 Snooping- Fast Leave- IGMP Snooping Querier- Static Group Config• Multicast VLAN Registration (MVR)• Multicast Filtering• MLD Snooping- MLD v1/v2 Snooping- Fast Leave- MLD Snooping Querier- Static Group Config• Limited IP Multicast (256 profiles and 16 entries per profile) További jellemzők • Automatic Device Discovery• Batch Configuration• Batch Firmware Upgrading• Intelligent Network Monitoring• Abnormal Event Warnings• Unified Configuration• Reboot Schedule IPv6 Support • IPv6 Dual IPv4/IPv6• Multicast Listener Discovery (MLD) Snooping• IPv6 neighbor discovery (ND)• Path maximum transmission unit (MTU) discovery• Internet Control Message Protocol (ICMP) version 6• TCPv6/UDPv6• IPv6 applications- DHCPv6 Client- Ping6- Tracert6- Telnet (v6)- IPv6 SNMP- IPv6 SSH- IPv6 SSL- Http/Https- IPv6 TFTP VLAN • VLAN Group- Max. 4K VLAN Groups• 802.1Q tag VLAN• MAC VLAN: 12 Entries• Protocol VLAN• GVRP• Voice VLAN Hozzáférés-jogosultsági lista (ACL) • Support up to 230 entries• Time-Range- Time Slice- Week Time-Range- Absolute Time-Range- Holiday• Time-based ACL• MAC ACL- Source MAC- Destination MAC- VLAN ID- User Priority- Ether Type• IP ACL- Source IP- Destination IP- IP Protocol- TCP Flag- TCP/UDP Source Port- TCP/UDP Destination Port- DSCP/IP TOS• IPv6 ACL• Combined ACL• Rule Operation- Permit/Deny• Policy Action- Mirror- Rate Limit- Redirect- QoS Remark• ACL Rules Binding- Port Binding- VLAN Binding• Actions for flows- Mirror (to supported interface)- Redirect (to supported interface)- Rate Limit- QoS Remark Biztonság • AAA• 802.1X- Port-based authentication- MAC (Host) based authentication- Authentication Method includes PAP/EAP-MD5- MAB- Guest VLAN- Support Radius authentication and accountability• IP/IPv6-MAC Binding- 512 Binding Entries- DHCP Snooping- DHCPv6 Snooping- ARP Inspection- ND Detection• IP Source Guard- 253 Entries- Source IP+Source MAC• IPv6 Source Guard- 183 Entries- Source IPv6 Address+Source MAC• DoS Defend• Static/Dynamic/Permanent Port Security- Up to 64 MAC addresses per port• Broadcast/Multicast/Unicast Storm Control- kbps/ratio control mode• Port Isolation• Secure web management through HTTPS with SSLv3/TLS 1.2• Secure Command Line Interface (CLI) management with SSHv1/SSHv2• IP/Port/MAC-based access control MIBs • MIB II (RFC1213)• Bridge MIB (RFC1493)• P/Q-Bridge MIB (RFC2674)• Radius Accounting Client MIB (RFC2620)• Radius Authentication Client MIB (RFC2618)• Remote Ping, Traceroute MIB (RFC2925)• Support TP-Link private MIBs• RMON MIB(RFC1757, rmon 1,2,3,9) VEZÉRLÉS Omada App Yes, through• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller Centralized Management • Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller Cloud Access Yes, through• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller. Management Features • Web-based GUI• Command Line Interface (CLI) through telnet• SNMPv1/v2c/v3• SNMP Trap/Inform• RMON (1,2,3,9 groups)• SDM Template• DHCP/BOOTP Client• Dual Image, Dual Configuration• CPU Monitoring• Cable Diagnostics• EEE• SNTP• System Log EGYÉB JELLEMZŐK Tanúsítványok CE, FCC, RoHS Csomagolás tartalma • SG2005P-PD• Mounting Kits• Installation Guide Rendszerkövetelmény Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. Környezet • Operating Temperature: -40 to 60 °C (-40 to 140 °F)• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
TP-LINK Switch 5x1000Mbps(4xPOE+), Easy Smart, TL-SG105MPE
5-Port Gigabit Easy Smart Switch with 4-Port PoE+ PORT: 4× Gigabit PoE+ Ports, 1× Gigabit Non-PoE Ports SPEC: 802.3af/at, 120 W PoE Power, Desktop Steel Case FEATURE: PoE Auto Recovery, MTU/Port/Tag-based VLAN, QoS, IGMP Snooping, Web/Utility Management,
TP-LINK Switch 8x100Mbps(8xPOE+) + 2x1000Mbps + 1xGigabit SFP, TL-SL1311P
Hardver jellemzők Csatlakozások • 8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port • AUTO Negotiation • AUTO MDI/MDIX Hálózati összeköttetés • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) Ventilátorok száma Fanless Fizikai biztonsági zár Yes Külső tápellátás External Power Adapter (Output: 53.5 VDC / 1.31 A) Csomagtovábbítási arány 5.6544 Mpps PoE portok (RJ45) • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 65 W MAC-cím tábla 2K Jumbo Frame 16 KB Switch kapacitás 7.6 Gbps Méretek (Sz x Mé x Ma) 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) Max. áramfelvétel • 5.61 W (220 V/50 Hz. no PD connected) • 77.32 W (110 V/50 Hz. with 65 W PD connected) Max Heat Dissipation • 19.13 BTU/h (no PD connected) • 263.7 BTU/h (with 65 W PD connected) Szoftver jellemzők Továbbítás módja Store-And-Forward További funkciók • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission) • Isolation Mode Button (Ports 1–8) • PoE Auto Recovery Button (Ports 1–8) • Mac Address Auto-Learning and Auto-Aging • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode Egyéb jellemzők Tanúsítványok FCC, CE, RoHS Csomagolás tartalma • TL-SL1311P • Power Adapter • Installation Guide Környezet • Operating Temperature: 0–40 ? (32–104 ?) • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
LINKEASY ipari switch,1xGE SFP+8x10/100/1000BaseTX, duál DC10~58V bemenet, DIN sín, -40~+85C
RÉSZLETEK Az ISW-108 egy nem menedzselt gigabit ethernet ipari optikai switch. 1 db 10G-s SFP és 8 db 10/100/1000BaseT(x) Auto MDI/MDIX Auto Negotiation RJ45 portal rendelkezik. Az eszköz ISW 108 PWR kivitele támogatja a PoE funkciót a 802.3af/at szabványnak megfelelően maximum 30W/port fogyasztással 240W összteljesítményig. Az eszköz kisméretű, passzív hűtésű, alacsony fogyasztású kialakítása lehetővé teszi a karbantartásmentes, alacsony költségekkel járó üzemeltetését. A termék tartósságát növeli a beépített villámvédelem és az antisztatikus kialakítás, működési hőmérsékelttartománya -40? és +85? fok közé tehető. Az eszköz széles körben alkalmazható ipari területeken és különböző szélessávú adatátviteli megoldásokban.
TP-LINK Switch 5x1000Mbps(1xPOE++/4xPOE+) Fémházas, TL-SG1005P-PD
Hardver jellemzők Szabványok és protokollok IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1p Csatlakozások • 5× 10/100/1000Mbps RJ45 Ports • 1× 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt Type3/bt Type4) • 4× 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at) • AUTO Negotiation • AUTO MDI/MDIX Hálózati összeköttetés • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) Ventilátorok száma Fanless Hálózati tápegység Only Powered by PoE Device PoE portok (RJ45) • PoE In Port: Port 5, Compliance with 802.3af/at/bt Type3/bt Type4 • PoE Out Ports: Ports 1-4, compliance with 802.3af/at • PoE Power Budget: -66 W when powered by 802.3bt Type 4 (90 W) -47 W when powered by 802.3bt Type 3 (60 W) -21 W when powered by 802.3at (30 W) -9 W when powered by 802.3af (15.4 W) Méretek (Sz x Mé x Ma) 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) Max. áramfelvétel • 2.68 W (90W PoE In, with no PD connected) • 68.59 W (90W PoE In, with 66 W PD connected) Max Heat Dissipation • 9.112 BTU/h (90W PoE In, with no PD connected) • 233.206 BTU/h (90W PoE In, with 66 W PD connected) Működési jellemzők Switching teljesítmény 10 Gbps Csomagtovábbítási sebesség 7.44 Mpps Fizikai (MAC) cím tábla 2k Szoftver jellemzők További jellemzők • Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery (Ports 1-4) • Mac Address Auto-Learning and Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping Továbbítás módja Store-And-Forward Egyéb jellemzők Tanúsítványok CE, FCC, RoHS Csomagolás tartalma • TL-SG1005P-PD • Installation Guide Környezet • Operating Temperature: -30–70 ? (-22–158 ?); • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
ZyXEL GS1900-8-EU0102F 8x GbE LAN port smart menedzselhető asztali switch
GS1900-8 GS1900-8HP GS1900-10HP GS1900-16 Product name 8-port GbE Smart Managed Switch 8-port GbE Smart Managed PoE Switch 8-port GbE Smart Managed PoE Switch with GbE Uplink 16-port GbE Smart Managed Switch Port Density Total port count 8 8 10 16 100/1000 Mbps 8 8 8 16 SFP 100/1000 Mbps - - 2 - PoE 802.3at PoE ports - 8 8 - Total PoE budget (Watts) - 77 77 - Performance Switching capacity (Gbps) 16 16 20 32 Forwarding rate (Mpps) 11.9 11.9 14.88 23.8 Packet buffer (byte) 525 K 525 K 525 K 525 K MAC address table 8 K 8 K 8 K 8 K Jumbo frame (byte) 9 K 9 K 9 K 9 K Power Input 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz Max. power consumption (watt) 5.0 84.8 95.3 10.2 Physical Specifications Dimensions (WxDxH) (mm/in.) 250 x 104 x 27/9.84 x 4.10 x 1.06 250 x 104 x 27/9.84 x 4.10 x 1.06 250 x 104 x 27/9.84 x 4.10 x 1.06 216 x 133 x 42/8.50 x 5.23 x 1.65 Weight (kg/lb.) 0.65/1.43 0.71/1.57 0.72/1.59 0.97/2.13 Environmental Specifications Acoustic noise (min/max, dBA) 0
Mikrotik CRS510-8XS-2XQ-IN Switch
Specifikációk Részletek Termékkód CRS510-8XS-2XQ-IN Architektúra MIPSBE CPU QCA9531 CPU-magok száma 1 CPU névleges frekvencia 650 MHz Kapcsoló chip modell 98DX4310 RouterOS licenc 5 Operációs rendszer RouterOS v7 RAM mérete 128 MB Tárolási méret 32 MB Tárolás típusa FLASH MTBF Körülbelül 200 000 óra 25 °C-on Vizsgált környezeti hőmérséklet -40°C és 70°C között Tápellátás Részletek AC bemenetek száma 2 AC bemeneti tartomány 100-240 DC bemenetek száma 3 (DC jack, 2 tűs csatlakozó, PoE-IN) DC jack bemenet Feszültség 36-57 V 2 tűs terminál bemenet Feszültség 36-57 V Frekvencia (Hz) 47-63 Max. energiafogyasztás 45 W Max. energiafogyasztás tartozékok nélkül 27 W Hűtés típusa 2 ventilátor PoE bemenet 802,3 BT PoE bemeneti feszültségben 42,5–57 V Ethernet Részletek 10/100 Ethernet portok 1 Optika Részletek 25G SFP28 portok száma 8 100G QSFP28 portok száma 2 Perifériák Részletek Soros konzol portja RJ45 Egyéb Részletek PCB hőmérséklet-monitor Igen Feszültségfigyelő Igen Tanúsítványok Részletek Tanúsítvány CE, EAC, ROHS IP 20 Csomag tartalma IEC kábel IEC kábel Rack fülek CRS510-hez K10 csavarkészlet Csatlakozó dugó
